SCORPION REWORK SYSTEM

SOLDER POT

NOZZLES

	Compare Scorpion Rework Models

	APR-1200-SRS	APR-1200-SRS-MOB	APR-1200A-SRS	APR-1200A-SRS-MOB	670050	670051
Rework Application	Standard	High density	Standard	High density	Standard	Standard
Placement Head	Manual	Manual	Motorized	Motorized	Manual	Motorized
Placement Force Sensor	No	No	Yes	Yes	No	Yes
Placement Accuracy	0.0254 mm	0.0254 mm	0.0254 mm	0.0254 mm	0.0254 mm	0.0254 mm
Minimum Component Size	0.4 mm x 0.2 mm	0.4 mm x 0.2 mm	0.4 mm x 0.2 mm	0.4 mm x 0.2 mm	0.4 mm x 0.2 mm	0.4 mm x 0.2 mm
Minimum Component Pitch	0.3 mm	0.3 mm	0.3 mm	0.3 mm	0.3 mm	0.3 mm
Max PCB Size	343 mm x Open	305 mm x Open	343 mm x Open	305 mm x Open	610 mm x Open	610 mm x Open
Max PCB Thickness	6 mm	6 mm	6 mm	6 mm	6 mm	6 mm
Camera Field-of-View	45 mm x 57 mm	25 mm x 25 mm	45 mm x 57 mm	25 mm x 25 mm	45 mm x 57 mm	45 mm x 57 mm
Camera Resolution	720p + 1080p	1080p	720p + 1080p	1080p	720p + 1080p	720p + 1080p
Nitrogen Compatible	No	No	No	No	Yes	Yes
Monitor Size	19 in.	22 in.	19 in.	22 in.	19 in.	19 in.
Remote Control	Analog	Analog	Digital	Digital	Analog	Digital
Country of Origin	USA	USA	USA	USA	USA	USA
